Zurn® 1260XL-A 2472441
  1. pin-int

Zurn® 1260XL-A 2472441

Zurn® 1260XL Series 1260XL-A Water Hammer Arrestor, 1/2 in, MNPT, 250 psi, 32 to 212 deg F, Copper, Lead-Free

  • Manufacturer: Zurn Elkay Water Solutions
  • Brand Name: Zurn®
  • Part Number: 2472441
  • MPN: 1260XL-A
  • UPC: 612052237046
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • loading Available at ST LOUIS
  • loading Available at All Branches

The Zurn® model 1260XL-A is ideal for use where lead-free fittings are required. It designed to protect residential, commercial and industrial water lines during pressure surges following quick valve closure. Z1260XL Series may be installed within a stud bay without the need for an access panel.

Zurn® Water Hammer Arrestor, 1260XL Series, 1/2 in Connection, MNPT Connection, 250 psi, Lead-Free, Copper, 32 to 212 deg F, 7/8 in Dia x 6-1/4 in L

Connection Size      :      1/2 in
Connection Type      :      MNPT
Dimensions      :      7/8 in Dia x 6-1/4 in L
Lead-Free/Contains Lead      :      Lead-Free
Material      :      Copper
Pressure Rating      :      250 psi
Series      :      1260XL Series
Temperature Rating      :      32 to 212 deg F
  • Size ''A'' features a fixture unit capacity of 1-11 with 1/2'' MNPT threaded ANSI/ASME B1.20.1
  • Features a temperature range -40 degrees to 212 degrees Fahrenheit
  • Rated with ASSE Listed 1010, ANSI A112.26.1, and Certified to NSF/ANSI 372 by IAPMO R&T
