Supco® CS189-227X110 2444965
  1. pin-int

Supco® CS189-227X110 2444965

Start Capacitor

  • Manufacturer: Lennox International
  • Brand Name: Supco®
  • Part Number: 2444965
  • MPN: CS189-227X110
  • UPC: 687152182985
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • loading Available at ST LOUIS
  • loading Available at All Branches
Agency      :      UL®, VDE®
Capacitor (MFD)      :      189 to 227 MFD
Capacitor Voltage      :      110VAC
Dimensions (DIAxH)(INCH)      :      1-7/16"x2-¾"
Operating Temperature      :      -40°F to 149°F (-40°C to 65°C)
  • Type two
  • Made at Supco in Nanchang. Jiangxi, China
  • Non-PCB biodegradable synthetic oil
  • Dry, electrolytic, non-polarized, types for intermittent duty in AC motors and compressors
  • Used where starting torques must be higher in relation to running torques
  • Moisture and oil resistant molded phenolic resin or plastic material
  • Standard dual blade terminals
  • Industry standard case sizes
  • Dimensions (DiaxH)(inch) 1-7/16 in x 2 No.190 in
  • Operating temperature -40 deg F to 149 deg F (-40 deg C to 65 deg C)
  • Agency UL®, VDE®
  • Capacitor (Mfd) 189 to 227 Mfd
  • Capacitor voltage 110VAC
