POWERS™ LFMM431 1 2418159

POWERS™ LFMM430 Series LFMM431 1 Master Tempering Valve, 3/4 in Nominal, NPT, 42 gpm, 125 psi, 90 to 160 deg F

  • Manufacturer: Watts Water Technologies
  • Brand Name: POWERS™
  • Part Number: 2418159
  • MPN: LFMM431 1
  • UPC: 686408614638
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • loading Available at ST LOUIS
  • loading Available at All Branches

Master tempering valves available in five sizes that temper water as high as 208 gpm and as low as 3 gpm. All valves are listed to ASSE 1017 and certified to CSA B125. Valves feature advanced paraffin actuation technology for dynamic response and excellent low flow temperature control. The LFMM430 line also features a single seat design for virtual shut down in the event of cold water failure, triple duty check stops with screens and a 5 deg F approach temperature for low temperature hot water supply.

POWERS™ Master Tempering Valve, LFMM430 Series, 3/4 in Nominal, NPT Connection, 125 psi, 42 gpm Flow Rate, 6.32 Cv Nominal Capacity, Water Media, Checkstop Actuator, 11.625 in Inlet to Outlet Length, Brass Body, Brass Handle, Finish: Rough Bronze, 90 to 160 deg F, 11 5/8 in L

Actuator Type      :      Checkstop
Body Material      :      Brass
Connection Type      :      NPT
Dimensions      :      11-5/8 in L
Finish      :      Rough Bronze
Flow Rate      :      42 gpm
Handle Material      :      Brass
Inlet to Outlet Length      :      11-5/8 in
Media      :      Water
Nominal Capacity      :      6.32 Cv
Nominal Size      :      3/4 in
Pressure Rating      :      125 psi
Series      :      LFMM430 Series
Temperature Rating      :      90 to 160 deg F
  • Vandal-resistant locking mechanism secures temperature setting
  • Virtual shut-off if supply pressure fails
  • Dirt and lime-resistant poppet and seat design
